Tamura 2DMB All-in-One DC-DC Converters/Gate Drivers offer a high insulation voltage (supports up to 1700V module), a low profile, and low stray capacity. Features include a 13VDC to 28VDC input voltage range, desaturation protection, and an auto-recovery protection release condition with either IGBT or SiC-MOSFET options. The 2DMB components are ideal for use in multiple applications, such as motor control units, battery chargers, robots, PV inverters, welding machines and more.
FEATURES
- All-in-one (built-in DC-DC converter/Gate driver)
- Dual output corresponding to 2 in 1
SPECIFICATIONS
- 13VDC to 28VDC input voltage range
- 3.3VDC to 5VDC logic input voltage
- 2 outputs
- ±35A peak output current (gate current)
- 100ns delay time
- Desaturation protection
- Auto recovery protection release condition
- Direct mode and half-bridge mode can be selected
- Withstand voltage
- 5000VAC primary to secondary
- 4000VAC secondary to secondary
- 5kVAC insulation voltage
- 12pF typ. stray capacity
- Temperature range
- Operating
- -40°C to +85°C for input voltages of 13VDC to 18VDC
- -40°C to +75°C for input voltages of 18VDC to 28VDC
- -40°C to +90°C storage
- Operating
- Ambient humidity
- 20% to 95% RH (no condensation) operating
- 5% to 95% RH (no condensation) storage
APPLICATIONS
- Inverters
- Motor control units
- Battery chargers
- Robots
- Industrial power supplies
- Welding machine
- PV inverters
- Wind power generation
