Features: Innovative of over temprature protection and capacitor failure protection,double protection of over pressure & over currect,internal discharge system,one form capacitor cane,self-healing & long useful life.
| Power Rate: | 1 to 50Kvar |
| Voltage Scope: | 100 to 1000V |
| Voltage Rate: | 230V,400V,440V,480V,525V,690V,815V |
| Over Voltage: | Un10%,Un15%,Un30% |
| Over Current: | 1.3 In,1.5In,1.8In |
| Power Losses: | less less 0.2W/Kvar |
| Tolerance: | +5%Cn to -5%Cn |
| Discharge: | less 50V within 3 min. |
| Protection: | over pressure,additional multi-protection of capacitor over temperature and capacitor failure automatic cut-off or alarm |
| Operation: | -25D,2500M Alt.,95% Hrel.IP20 |
| Life Expectancy: | 130000.00 to 180000.00 hours. |
| Standard: | IEC831-1(2)/EN831-1(2),VED0560 |
| Specification protection terminals | |
| Rate Voltage: | 220V,+10% to -10% |
| Rate Current: | 10A |
| Over temperature: | Over 80 to 100C automatic cut-off or alarm |
| Failure protection: | automatic cut-off or alarm |
| Cable connection: | m6 stud |
Series low voltage multi-protection capacitors were designed to compensate the reactive energy and the line loss in power networks up to 1000V,the loads like normal load or with harmonics content permitting,in additional an special protection function.
Application
Automatic power factor correction (PFC) andcapacitor banks
Individual solution for fixed power factorcorrection (e.g. Motor, transformers, lighting etc.)
Group fixed power factor correction(several equipment connected in a group)
Capacitor banks of tuned and detuned
Harmonic trap applications (e.g. UPS,frequency drives and converters etc.)
Special application such as outdoor mounting,filter model, bushing terminal style etc.
Benefit:
Electrical
Long life cycle (100000 hours)
Highest pulse current withstand capability(200In)
Corona-free
Very low losses
Internal discharge resistor
Terminal for high capacity cables (up to 16 to 32mm²) , both side of the terminal can be used
Mounting:
Reduced mounting costs
Any position mounting
Maintenance-free
Environment:
Non-pollution, Non PCB
Environmentally friendly manufactured
Recyclable
Easy to dispose
Save energy and reduce Carbon dioxideemission!
Safety:
Dry type design
Excellent self-healing ability
Overpressure and over-current disconnector
Non-flammable
Touch-proof terminals
Three cascade cylinder sealing
One form capacitor cane, no possibility forleaks
