Showing 1–24 of 27 results
-
Bussmann / Eaton 0603ESDA2-TR2 PolySurg™ ESD Suppressor is designed to provide ESD protection for high frequency, low voltage applications. The device features a 0603 footprint, very low leakage current, ultra-low capacitance (0.15pF max), and a fast response time, and exceeds testing IEC 61000-4-2 standards. The ultra-low (0.15pF maximum) capacitance enables the 0603ESDA2-TR2 ESD Suppressor to...
-
-
Tamura 2DMB All-in-One DC-DC Converters/Gate Drivers offer a high insulation voltage (supports up to 1700V module), a low profile, and low stray capacity. Features include a 13VDC to 28VDC input voltage range, desaturation protection, and an auto-recovery protection release condition with either IGBT or SiC-MOSFET options. The 2DMB components are ideal for use in multiple...
-
N-CHANNEL ENHANCEMENT MODE MOSFET
-
Part No Emitting Color Chip Vf (V) @20mA lv(cd) @20mA Viewing angle 2Θ½ Material CCT(K) Min Max Min Max AM-LG-020WKZ-L2-T20 White InGaN X: 0.287-0.318 Y: 0.276-0.329 2.8 3.6 1000 2000 110
-
Part No Emitting Color Chip Vf (V) @150mA *@ 60mA Luminous Flux (lm) @150mA * lv(mcd) @60mA Viewing angle 2Θ½ Material λD (nm) (Typ) Min Max Min Max AM-LG-2835UYR-HC-T60 Amber AlGaInP 590 * 1.9 * 2.8 2000 4000 120 AM-LG-2835URFS-HC-T120 Red AlGaInP 625 1.75 3.05 16 28 120
-
Part No Emitting Color Chip Vf (V) @50mA lv(mcd) @50mA Viewing angle 2Θ½ Material λD (nm) (Typ) Min Max Min Typ AM-LG-P192UYR-T50 Amber AlGaInP 590 1.9 2.8 450 800 130
-
-
Comchip Technology BZT52Cx Zener Diodes feature a Zener breakdown voltage range from 2V to 75V, a Zener current range from 0.045µA to 150.0µA, and a Zener dynamic impedance range from 10Ω to 255Ω. These devices offer high stability and high reliability, with a 250°C/W junction to ambient thermal resistance rating and a wide -65°C to +150°C...
-
Features: Silicon epitaxial planar diode Leadfree and RoHS compliance components Mechanical Data Size: 0805 Weight: approx. 6mg Marking: Cathode terminal Download: PDF
-
Designed to protect voltage sensitive electronic components from ESD and other transients. Excellent clamping capability, low leakage, and fast response time provide best in class protection on designs that are exposed to ESD. The combination of small size, high level of ESD protection makes them a flexible solution for applications such as HDMI, Display Port...
-
Comchip Technology CPDWL5V0-HF SMD Electro-Static Discharge (ESD) Protection Diode is designed for bi-directional ESD protection. This ESD diode features high component density, low clamping voltage, and low leakage. The CPDWL5V0-HF diode offers ±18kV ESD capability and 5V working peak reverse voltage (VRWM). This diode comes in a 01005 molded plastic surface mount package. Features: Bi-directional ESD...
-
NPN LOW VOLTAGE AVALANCHE TRANSISTOR IN SOT23
-
The H21Ax and H22Ax series of opaque photointerrupters are single channel switches consisting of a Gallium Arsenide infrared emitting diode and a NPN silicon photo transistor mounted in a polycarbonate housing. The package is designed to optimise the mechanical resolution, coupling efficiency, ambient light rejection, cost and reliability. Operating on the principle that objects opaque...
-
The H21Ax and H22Ax series of opaque photointerrupters are single channel switches consisting of a Gallium Arsenide infrared emitting diode and a NPN silicon photo transistor mounted in a polycarbonate housing. The package is designed to optimise the mechanical resolution, coupling efficiency, ambient light rejection, cost and reliability. Operating on the principle that objects opaque...
-
Features: For surface mounted applications Low reverse leakage current Low forward voltage drop High surge capacity Meet UL flammability classification 94V-0 Mechanical Data Case: JEDEC A-SMA molded plastic Polarity: Color band denotes cathode Mounting position: Any Download: PDF
-
Features: Dual Swithching Diode Fast Switching Speed Surface Mount Package Ideally Suited for Automatic Insertion For General Purpose Switching Applications Download: PDF
-
Comchip Technology MMBTx General Purpose Transistors are NPN and PNP bipolar devices designed for high gain, low-noise, amplifier, and switching applications. These devices offer high energy efficiency due to low heat generation and feature low collector-emitter saturation voltage. The Comchip Technology MMBTx General Purpose Transistors are offered in an industry-standard, low-profile SOT-23 package, well-suited for pick-and-place assembly. Features:...
-
Feature: Reliable low cost construction utilizing molded plastic technique Both bi-directional and uni-directional devices are available Fast response time Excellent clamping capacity 400 W peak pulse power capability with a 10/1000 μs waveform, 7 repetition rate (duty cycle): 0.01% Download: PDF
-
Introduction:
- Case：DO-15
- Power：600W
- Reverse Stand-Off Voltage: 5.8~512V
- Glass passivated junction
Excellent clamping capability
- Fast response time:typically less than 1.0ps
- Fast response time:typically less than 1.0ps
-
Bussmann / Eaton PolySurg™ Four-Channel ESD Suppressor (42510ESDA-TR1) protects sensitive electronic circuits from ESD without distorting data signals. The SMT four-channel array provides protection through its ultra-low capacitance (0.1pF typical) and is well suited for HDMI ESD protection applications. Halogen-free, lead-free, and RoHS compliant, Bussmann / Eaton PolySurg™ Four-Channel ESD Suppressor provides fast response time...
-
Features: Fast switching for high efficiency Low cost RoHS Low reverse leakage current COMPLIANT High current capability Low forward voltage drop Meet UL flammability classification 94V-0 Mechanical Data Case: ITO-220AC Molded plastic Polarity: Polarity: As marked on the body Mounting position: Any Download: PDF
-
Introduction:
- Case: DO214AC
- Power: 400W
- Reverse Stand-Off Voltage: 5.0~440V
- Glass passivated junction
- Excellent clamping capability
- Fast response time:typically less than 1.0ps
-
Introduction:
- Case: DO-214AC
- Power: 400W
- Reverse Stand-Off Voltage: 11～440V
- Glass passivated junction
- Excellent clamping capability
- Fast response time: typically less than 1.0ps
- Fast response time:typically less than 1.0ps
