The W534811(xx)SA - Single Row and W534821(xx)SA - Dual Row Series header sockets use a gold plated phosphor bronze contact. The moulding material is 30% GF Nylon rated to UL 94 V-0. The (xx) in the part number relates to the number of pins required. Sockets are available up to 32 pins for the single...
-
The W5811(xx)SB1RC - Single Row and W5821(xx)SB1RC - Dual Row Series headers use a gold plated phosphor bronze pin. Moulding material is 30% GF Nylon rated to UL 94 V-0. The (xx) in the part number related to the number of pins required. Headers are available up to 32 pins for the single row and...
-
The W3100 Series uses a phosphor bronze contact with 2 plating options RoHS compliant Tin or Tin/Lead . The standard moulding material is 30%GF PBT rated to UL 94 V-0. Designed for automatic PCB loading machines, features include: Overstress protection Large target area for ease of IC insertion 35 degree angled contact to prevent the...
-
These two-row socket strips have 2.54 mm pitch, solder termination and straight body orientation for easy installation. It supports through-hole mounting for vertical stacking of PCBs. The sockets incorporate straight tri-beam tin plate contacts for precise connection. It provides a variety of connector option to cover the majority of board-to-board, bussing and programming requirements. Download:...
-
The W30600 Series uses a screw machined half hard brass outer pin with a beryllium copper contact. The beryllium copper contact can be Gold or pure Tin. The Outer pin has 3 plating options; RoHS compliant Tin, Tin/Lead or Gold. The moulding material is 30%GF PBT rated to UL 94 V-0 and features include a...
-
The W36600 Series uses a screw machined half hard brass outer pin with a beryllium copper contact, available in Gold or pure Tin. The Outer pin has 3 plating options; RoHS compliant Tin, Tin/Lead or Gold. The moulding material is 30%GF PBT rated to UL 94 V-0 and features include a pin incorporating a straight...
