EMI Filters Up to 28 A Output Current Up to 500 W Output Power Active Surge Protection MILSTD 461 and DEFSTAN 59411 MILSTD 1275 and DEFSTAN 615 MILSTD 810 3 Year Warranty Specifications Dimensions DSF100: 1.57 x 1.25 x 0.52 in (39.9 x 31.9 x 13.2 mm) DSF200LV: 2.41 x 1.45 x 0.51 in (61.2...
-
High Voltage AC-DC 1.2kW Regulated 1 kV to 60 kV Rack Mount 2U Rack Mount Low Ripple and Tight Regulation Constant Voltage/Constant Current Operation Specifications: Dimensions 3.375 x 17.0 x 20.5 in (85.7 x 431.8 x 520.7 mm) Input Voltage 180 to 264 VRMS single-phase, 48-63 Hz, 1500 VA maximum at full load. C14 connector...
-
EMI Filters IEC320-C14 Filtered Inlet Screw Mount & Snap-in Versions Compact Design ITE Version 1, 3, 6 & 10A Rating 6.3 x 0.8mm Faston Terminals Bleed Resistor Shielded Metal Body Wide Operating Temperature Range 3 Year Warranty Specifications Dimensions Panel mount, screw fix (SFR): See datasheet Panel mount, snap-in (PFR): See datasheet Input Voltage 0...
-
EMI Filters Chassis Mount Filter Single Stage Design Compact Design ITE Version 1, 3, 6, 10, 15 & 20A Rating 6.3 x 0.8mm Faston Terminals Bleed Resistor Shielded Metal Body Wide Operating Temperature Range 3 Year Warranty Specifications Dimensions Chassis mount (1FR & 2FR): See datasheet Input Voltage 0 to 264 VAC Operating Temperature -40...
-
AC-DC Power Supplies 250 W Convection & 500 W Forced-cooled Ratings 5 V Standby Output Universal 85 - 264 VAC Input IT & Medical Safety Approvals -40° C to +70° C Operation Power Fail, Remote On/Off & Remote Sense Class B Emissions Specifications: Dimensions GCU500: 3.30 x 6.50 x 1.55‚ (83.8 x 165.1 x 39.3...
-
High Voltage DC-DC High Voltage DC-DC Converters +24VDC Input [22 to 30V] Output Voltage & Current Regulated 0 to 100% Programmable Output & Current Voltage & Current Monitor Outputs Operating Temperature: -40°C to +70°C Short Circuit, Arc, and Overload Protections On-board +5V Reference Efficiency >80% Low Ripple <0.05% Premier Thermal Performance Specifications: Dimensions HRL30: 3.0...
