SPECIFICATION
| Current Rating | 0.5A per pin |
|---|---|
| Voltage Rating | 50V AC/DC |
| Contact Resistance | 40mΩ |
| Insulation Resistance | 250MΩ |
| Dielectric Withstanding Voltage | 250VAC |
| Durability | 30 Cycle |
|---|---|
| Insertion Force | 13N max. |
| Extraction Force | 16N max. |
| Operating temperature range | -40℃~+85℃ |
|---|---|
| Storage temperature range | -40℃~+85℃ |
| Recommended IR Reflow(Wave Soldering) Temperature | 260℃ |
|---|
