Description
The contact rating of Dailywell DTS/TME series tact switches up to DC 12V 50mA and SPST function is available.
The operating force is 160±50gf and 260±50gf. and the machinacal durability up to 100,000 cycles min.
Order Terms
1. Your inquiry will be answered within 24 hours.
2. Payment term: T/T in advance (first transaction)
3. Term of trade: FOB HK/TW
4. Mini Order Quantity: 100 PCS per item.
5. Mini Order Amount Per Shipment: USD$50
6. Lead time: 3-4 weeks.
SPECIFICATION
- CONTACT: Mechanical contact.
- CIRCUIT: SPST.
- RATING: DC 12V 50mA.
- TRAVEL: 0.3± 0.15mm.
- OPERATING FORCE: 160± 50gf ; 260± 50gf.
- CONTACT RESISTANCE: 100mΩ max.
- LIFE: 100,000 Cycles min.
APPLICATIONS
- Communication equipment and Audio visual equipment.
