Output Wattage:
Best Solution For:
- Server ,Workstation ,Storage System ,IPC
Dimension:
- 140x150x86(mm)
- 5.51×5.91×3.39(inch)
Input Spec:
- VOLTAGE: DC 110~220VDC
- INPUT CURRENT: 20/40 AMPS@110VDC/220VDC
- STEADY-STATE CURRENT: 7A TYPICAL
- INRUSH CURRENT: 20/40 AMPS @ 110VDC/220VDC
Features:
- TEMPERATURE RANGE: OPERATING 0℃ ~ 50℃, STORAGE -20℃ ~ 80℃
- HOLD UP TIME: When power shutdown DC output 5V must be maintain 16msec in regulation limit at normal input voltage
- POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms
- OVER POWER PROTECTION: 110%~160%
- OVER VOLTAGE PROTECTION: +5V→5.6V～6.5V, +3.3V→3.6V～4.3V, +12V→13.2V～15V
- SHORT CIRCUIT PROTECTION: +5V、-5V、+12V、-12V、+3.3V
- OVER CURRENT PROTECTION: +3.3V→22~30A, +5V→22~30A, +12V→41.8~57A
- THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
