| EU RoHS |
Compliant with Exemption |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| Input Type |
DC |
| Maximum Input Voltage (V) |
27 |
| Maximum Input Current (mA) |
19 |
| Maximum Output Voltage (V) |
280(RMS) |
| Maximum Output Current (A) |
30(RMS) |
| Output Device |
MOSFET |
| Output Type |
AC |
| Minimum Load Current (mA) |
250(RMS) |
| I/O Isolation Voltage (V) |
3750(RMS) |
| Circuit Arrangement |
1 Form A |
| Minimum Operating Temperature (°C) |
-30 |
| Maximum Operating Temperature (°C) |
80 |
| Pin Count |
4 |
| Mounting |
Screw |
| Package Height |
14.3 |
| Package Length |
21.1 |
| Package Width |
36.6 |
| PCB changed |
4 |
