GCU500 Series

AC-DC Power Supplies

• 250 W Convection & 500 W Forced-cooled Ratings
• 5 V Standby Output
• Universal 85 – 264 VAC Input
• IT & Medical Safety Approvals
• -40° C to +70° C Operation
• Power Fail, Remote On/Off & Remote Sense
• Class B Emissions

---

Specifications:

• Dimensions
  GCU500: 3.30 x 6.50 x 1.55‚ (83.8 x 165.1 x 39.3 mm) GCU500-EF: 3.30 x 8.24 x 1.64‚ (83.8 x 209.3 x 41.7 mm)
• Input Voltage
  80 to 264 Vac (see datasheet)
• No Load Input Power
  115 Vac: 1 W 230 Vac: 6 W
• Harmonic Currents
  EN61000-3-2 Class A
• Efficiency
  92% 230 VAC, Full load
• Operating Temperature
  -40 to +70 °C (see datasheet)
• Isolation
  4000 VAC Input to Output (2 x MOPP) 1500 VAC Input to Ground (1 x MOPP) 500 VDC Output to Ground
• Worldwide Safety Approvals
  IEC62368-1 Ed 2, IEC60950-1, IEC60601-1 Ed 3 including risk management
• European Safety Approvals
  EN62368-1, EN60601-1/2006
• US Safety Approvals
  UL62368-1, CSA 22.2, No.62368-1, ANSI/AAMI ES60601-1:2005 & CSA C22.2, No.60601-1:08
• Other Safety Approvals
  LVD & RoHS
• EMC
  EN55011/32 Class B conducted EN55011/32 Class A radiated (Class B with 2T on Fair-Rite 2643800502 on output cable)
