Cable Type
Layout 103G1 (3pos.)
North America
- SJOOW: 300V, 90C
- UL listed and CSA certified for indoor and outdoor use
- UL-62/CSA C22.2-49
- Fire and smoke MSHA approved
- RoHS compliant
- Resistant to: oil, ultraviolet (uv), wate
Europe
- H07RN-F : 750V / -25?C to +60?C
- Outer sheath : rubber compound EM2 in acc. to HD 22.1 that is VDE 0282 part 1
- Colour outer sheath : black
- Core section : 2.5mm?
- Flame retardant in acc. to IEC 60332-1-2 resp. VDE 0482 part 332-1-2
- Resistant to Oil, UV, Solvents, Water, Ozone, aging and abrasion
Layout 102G1W3 (6pos.)
North America
-
SJOW: 300V, 90C
-
UL listed and CSA certified for indoor and outdoor use
-
Black neoprene outer sheath
- RS-485 communication (TSP #22 or TSP#24) and power (3 x AWG#14 or 3 x AWG#16) cable
Europe
- Rated Voltage: 450/750V
- Black PUR outer sheath for indoor and outdoor applications
- RS-485 communication (2 x 0.22mm? + braid) and power (3 x 1.5mm? or 3 x 2.5mm?) cable
