The RF front end of MC-1612-V3b is specifically designed to comply with sensitivity specification contained in AIS 140 standard (please refer to note in the Fig 3-2). It is the best solution to those customers that design tracking applications in compliance with AIS 140.
FEATURES
- Support GPS, GLONASS, GALILEO, BEIDOU, QZSS and NAVIC
- Capable of SBAS (WAAS, EGNOS, MSAS, GAGAN) and QZSS SLAS
- Support 135-channel GNSS
- Ultra low power consumption (option)
- Fast TTFF at low signal level
- Free hybrid ephemeris prediction to achieve faster cold start
- Up to 10 Hz update rate
- ±15ns high accuracy time pulse (PPS)
- Support Linux and Android OS driver
- Protocol support binary output
- IATF 16949 quality control
- Small form factor 16 x 12.2 x 2.4 mm
- SMD type with stamp holes; RoHS compliant
SPECIFICATION
| MC-1612-V2b | MC-1612-V3b | ||
| Satellite System | GPS + QZSS + GALILEO + GLONASS + BEIDOU | GPS + QZSS + GALILEO + GLONASS + BEIDOU+IRNSS | |
| Interface | UART | ||
| Input Voltage | 3.1V – 4.5V | ||
| Power(mA) | 58mA | 35mA | |
| VB (uA) | 64uA | ||
| Operating Temp (°C) | -40 ~ 85 | ||
| Dimension (mm) | 16 x 12.2 x 2.4 mm | ||
APPLICATIONS
- Personal positioning and navigation
- Automotive navigation
- Marine navigation
- Femtocell、Small-cell timing device
