Specification |
||
| Convention | ||
| Standard | M8 IEC 61076-2-104 | |
| Number of contacts | 3 | |
| Coding | A – coded | |
| Connector Style | 180°Male | |
| Termination | Solder | |
| Operating temperature | -25 °C … 80 °C | |
| IP Rating | IP67 | |
| Mechanical operation | >100 | |
| Torque | 0.3 Nm … 0.4 Nm | |
| Installation type | Front mounting M8 x 0.5 | |
| Electrical properties | ||
| Rated current (40oC) | 4A | |
| Rated voltage | ||
| 850V | ||
| Contact resistance | <10mΩ | |
| Insulation resistance | ≥100MΩ | |
| Degree of pollution | 3 | |
| Overvoltage category | II | |
| Material | ||
| Flammability rating according to UL 94 | V0 | |
| Contact material | CuZn | |
| Contact surface material | Au | |
| Contact material | PA | |
| Sealing material | NBR | |
| Cable gauge | ||
| Conductor cross section | 0.25mm² | |
| AWG signal line | 24 AWG | |
| Wire colors | Brown, blue, black | |
| Material conductor insulation | TPE / PVC | |
| Wire Length | 500mm | |
| Environmental protection | ROHS | |
| Key Commercial Data | ||
| MOQ | 100 PCS | |
