Output Wattage:
Dimension:
- 245x76x84(mm)
- 9.65×2.99×3.31(inch)
Input Spec:
- VOLTAGE: 90～264VAC
- FULL RANGE FREQUENCY: 47～63HZ
- INPUT CURRENT: 13.5A (RMS) FOR 115 VAC / 10.5A (RMS) FOR 230 VAC
- INRUSH CURRENT: 35 AMPS @230 VAC (at 25 degrees ambient cold start for each power unit)
- FC: UP TO THE TARGET OF 99% @230V, FULL
Features:
- TEMPERATURE RANGE: OPERATING 0℃～50℃, STORAGE -40℃~70℃.
- HOLD UP TIME: WHEN POWER SHUTDOWN ALL THE DC OUTPUT VOLTAG MUST BE MAINTAIN 10mS IN REGULATION LIMIT AT NORMAL INPUT VOLTAGE (70% LOAD).
- THE MAXIMUM POWER SUPPLY SYSTEM EFFICIENCY SHALL BE 8.
