Showing 25–48 of 147 results
-
-
97 Series Connectors
Amphenol Industrial’s 97 Series is a widely used connector series for the automotive, robotics, machine tool, and welding industries, as well as numerous other commercial applications from heavy equipment to ECG monitoring cables.
Shell components are fabricated from high grade aluminum alloy to provide strength and environmental protection. This family of connectors offers a wide variety of shell styles, contact patterns and accessory options.
-
984-3x-6051xx
Mini USB Connector is mainly mounted on PC Board as I.O. port of 3C products such as cellphone, multi-media players, tablets, GPS, camera, camcorder and some other hand-held devices for power charging and data transfer.
Application: Board to Wire
Apply to Industries: PC, IPC, Consumer Electronics, Automotive, Home Appliance, Medical -
984-3x-6056xx
Mini USB Connector is mainly mounted on PC Board as I.O. port of 3C products such as cellphone, multi-media players, tablets, GPS, camera, camcorder and some other hand-held devices for power charging and data transfer.
Application: Board to Wire
Apply to Industries: PC, IPC, Consumer Electronics, Automotive, Home Appliance, Medical -
984-73-2052xx
Micro USB Connector is mainly mounted on PC Board as I.O. port of 3C products such as cellphone, multi-media players, tablets, GPS, camera, camcorder and some other hand-held devices for power charging and data transfer.
Application: Board to Wire
Apply to Industries: PC, IPC, Consumer Electronics, Automotive, Home Appliance, Medical -
984-7x-8052xx
Micro USB Connector is mainly mounted on PC Board as I.O. port of 3C products such as cellphone, multi-media players, tablets, GPS, camera, camcorder and some other hand-held devices for power charging and data transfer.
Application: Board to Wire
Apply to Industries: PC, IPC, Consumer Electronics, Automotive, Home Appliance, Medical -
AC Charging Connector T1V-03
Special Features: Easy Operation Ergonomically designed grip shape. Weight Saving A 30% weight reduction over our current connector improves handling. Improved External Design Improved the external design without screw holes. Safety Structure To be certified by the standard of various countries (Japan, US, Canada, Europe), and securing contact reliability and safety. * Already certified by... -
AC Charging Inlet T1L-02
Special Features: Use of a Cap Damper Opening and Closing operations are gentle and smooth. Dustproof and Waterproof Dustproof and waterproof cap is equivalent to IP55. Specifications: Rated voltage 100 to 250V AC 120/240V AC Rated current 40A (JPN/EU) 40A (USA) Number of poles POWER 2, GROUND 1, SIGNAL 2 Ambient temperature -40° to +60° -
AC3168-02
Product Description Compatible with HDMI 1.4 / 2.0 /2.1 spec；Support 8K All HDMI connectors are approved by HDMI Org. Daily production capacity: 15~20K Monthly production capacity : 4KK~5KK Highly automated assembly on production line Housing: Thermoplastic, UL94V-0 Rated Contact: Copper Alloy ；Shell Copper Alloy Withdrawal force (Type A) : Initial 9.8N (1.0kgf) Min. & 39.2N... -
ACCELERATE® HD
ACCELERATE® HD ACCELERATE® HD ULTRA-DENSE MULTI-ROW MEZZANINE STRIPS
These 0.635 mm pitch high-density multi-row mezzanine strips feature up to 240 high-speed Edge Rate® contacts in a slim, low-profile design.
-
AE105E11B2PB-LC
HIGH-PERFORMANCE CONNECTORS FOR HARSH ENVIRONMENTS
Conesys D38999 connectors (Series I) are subminiature connectors that are qualified to MIL-DTL-38999 standard, making them ideal in tight spaces requiring exposure to harsh environments. They feature bayonet coupling and are 100% scoop-proof, with 5 receptacle mounting styles available. These Conesys D38999 connectors are suited for smaller wire gauge applications and have a durability of 500 mating cycles, with RFI and EMI shielding. -
AMJ-46XRDXX145-72
- Pin: 6
- Contact Pin: 4 / 6
- Mounting Type: DIP
- Connect Angle: Right Angle
- Layer: Single
- Contact Type: Reverse
- Port Number: 4
- Height (mm): 14.5
- Features: Low Profile
-
AMJ01883G1Z0E6-129
- Pin: 8
- Contact Pin: 8
- Mounting Type: DIP
- Connect Angle: Right Angle
- Layer: Single
- Contact Type: Reverse
- Port Number: 1
- Height (mm): 13.4
- LED: LED
-
AWJ-144RDXX115-72
- Pin: 4
- Contact Pin: 4
- Mounting Type: DIP
- Connect Angle: Right Angle
- Layer: Single
- Contact Type: Positive
- Port Number: 1
- Height (mm): 11.5
-
BAYONET CONNECTORS
The most well known Bayonet type connector is the BNC connector, which was initially introduced to make it easy to connect and disconnect, in comparison to screw-on connectors. The BNC series is still very popular for low frequency test equipment. It has been made available in multiple versions, 50 and 75 ohms, high voltage, isolated,... -
BK13C Series
Features 0.35mm Pitch / 0.6mm Stacking Height / 1.9mm Width Low-Profile Hybrid FPC-to-Board Connector Supporting 5A 1. Low-profile design with high current power supply capability - Rated current: 5A for power contact, 0.3A for signal contact - 0.6mm stacking height, 1.9mm width 2. Full armored design prevents housing damage 3. Easy mating operation with wide... -
BM46 Series
Features 1. Multi-RF capable Board-to-Board connector, World’s smallest width class Pitch : 0.35mm, Width : 2.0mm, Stacking height : 0.6mm 2. Contact design ideal for both high-speed digital transmission and RF signal 3. Superior RF Signal Transmission V.S.W.R. 0～3GHz ：1.3MAX 3～6GHz ：1.4MAX 6～12GHz：1.6MAX 4. Center shield prevents signal noise between opposing rows 5. Robust metal... -
Board to Board Connectors
Product Details Model Number:5BB121C34F Key Specifications/Special Features: Specifications: Current rating: 0.5A Insulation resistance: 100MΩ min Contact resistance: 20MΩ max Dielectric voltage: 500V AC for one minute Operating temperature: -40 to +105°C Materials: Insulator: polyester, UL 94V-0 Terminal: copper alloy -
Brass Adapter
Precision-machined, SAE-approved Eaton brass adapters are manufactured out of durable CA-360 brass. This provides outstanding corrosion resistance for a variety of applications from air brake to hydraulic and pneumatic systems. Regardless of the job, Eaton has just the right brass adapter to meet the challenge every time.
-
-
-
CFP Connectors & Accessories
CA009 Series CFP Connectors and Mechanical units for 40Gbps/100Gbps Ethernet:
- Riding heat-sink ensures efficient thermal dissipation
- Gasket installed host connector cover and Bracket to ensure EMI shielding performance
- Applicable module: All CFP MSA compliant optical modules with 40Gbps & 100Gbps
- Mating cycles:200cycles
-
CFP2 ~ CFP2-64G Connectors & Accessories
CN121X-104 Series CFP2, CFP2-56G, and CFP2-64G Connectors and Mechanical units for 100/400Gbps Ethernet
- CFP MSA SPEC compliant
- Offers both connectors and heat sink modules
- Offers both side-to-side & front-to-back heat sink
- Offers both single & dual-slot designs
- Meets CEI-28G-VSR requirement defined by OIF
- Best fit for CFP2-ACO (Analog Coherent Optics) solutions (CFP2-56G & CFP2-64G)
- Works for future 56G-NRZ channel and 100G-PAM4 chaneel (56G CFP2 connectors)
- Works for future 64G ACO and 100G-PAM4 chaneel (56G CFP2 64G connectors)
- Supports 100/400 Gb Ethernet systems.
- Mechanical Components compatible between standard CFP2, 56G CFP2, and CFP2 64G connectors
-
CFP8 Connectors and Accessories
CN168X-124 Series CFP8 Connector and Mechanical units for 400Gbps Ethernet
- Compliant with CFP-MSA CFP8 Design Guideline
- Work at 400GbEthernet CDAUI-16 and CDAUI-8 electrical signal
- Perform at 28GBaud signal (28G-NRZ & 56G-PAM4) and future 56GBaud signal (56G-NRZ & 100G-PAM4)
- Supports 16 channel (32 diff. pairs) high speed signals
- Support Belly-to-Belly Mount design
- Supports both Single and Dual-Port designs
