Features:
Motor Life
- Motors designed for long life
- Standard 2 year warranty
Motor Safety
- Standard models cUL and TUV/CE approved
- Impedence or thermal protection
Motor Construction
- Over 20 standard bearing/stator mounting configurations
- Custom bearing/stator mounting castings available upon request
Terminations
- Up to four taps available per motor bobbin
- Terminations include include 1/4” quick connect on bobbin, leads or custom connectors
Insulation System
- Insulation Classes B, F, and H available for a range of operation temperatures
- Face mount threaded studs standard with various air moving components found in tables on page
Specifications
| Diameter | Voltage AC | Frequency (Hz) | Insulation Class | Bearing Type | Shaft Configuration | Shaft Material | Speeds | Agency |
| 0.375-2.0 | 110/115/120/208/230/240 | 50/60 Hz, 60 Hz, 50 Hz | B, F, H | Sleeve, Ball, or Needle | Dual or Single | Stainless, or High Carbon Steel | Single or Multi | cUL, TUV/CE |
