Appleton™ PXSS2K Series Compound Barrier Type Cable Connectors are flameproof Class I cable connectors suitable for unarmored, extra hard usage, tray (TC) and shipboard cables. It provides an environmental seal on the cable jacket and an explosionproof compound barrier seal around the cable inner cores.
Features:
- The connector is UL Listed for NPT or Metric entry threads
- Continuous operating temperature: -60 °C to +85 °C (-76 °F to +185 °F)
- Sealing technique: displacement seal concept
- Sealing area(s): inner compound barrier and outer sheath
Specifications
- NEC/CEC Certifications and Compliances
Class I, Division 1, Groups C, D; Class I, Division 2, Groups A, B, C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 4X; IP66, IP67, IP68 - ATEX/IECEx Certifications and Compliances
Zone 1; Ex d IIC; Ex e IIC; Ex nR II, Ex tD; IP66, IP67, IP68 - Gland Material
Brass fully nickel plated - Seal Material
SOLO LSF (low smoke fumes) thermoplastic elastomer - Compound Material
Epoxy putty - Optional Material
Aluminum (replace last digit suffix 5 with 1) or 316L stainless steel (replace last digit suffix 5 with 4) - Cable Gland Accessories
Shroud, locknut, earth tag, entry thread seal, serrated washers, adaptors and reducers
