These stranded wire UL and CSA recognized grounding clips attach easily over panel or hole edge top to achieve positive ground wire contact with panel, plate or frame. Wire contact is achieved by either quick connect terminals or insulation displacement. Wire stripping, soldering and termination not required. For 18 to 12 gauge stranded wire.
UL File Number E54730
CSA File Number LR34995
Specifications |
||||||||||||||||||
| Part Number | Style | Panel Thickness Range A | ||||||||||||||||
| min | max | |||||||||||||||||
| 8182-84-00-0555 | 1A | 0.020 | 0.078 | |||||||||||||||
| 8182-84-01-0555 | 1A | 0.078 | 0.125 | |||||||||||||||
NOTE: Dimensions listed are nominal.
