ELECTRICAL SPECIFICATIONS
Power 25 W (max) Voltage Switching 150 VDC (max) Breakdown 250 VDC (min) Current Switching 1 Amp (max) Carry 5.4 Amp (max) Resistance Initial Contact Resistance 0.1 Ohm (max) Insulation Resistance 1E9 Ohm (min) Capacitance Contact 3.5 pF (typical) Temperature Operating -40 TO + 125 °C Storage -40 TO + 200 °C MAGNETIC SPECIFICATIONS
Pull – In Range 20-50 Ampere Turns Test Coil Coil III NARM RS-421-A PHYSICAL/OPERATIONAL SPECIFICATIONS
Capsule Volume Excluding Leads .73 cc-Nominal Contact Material Rhodium Glass Length 32.77 mm
