Product Technical Specifications
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Type | Axial |
| Product Category | AC Fan |
| Voltage Rating (V) | 115 |
| Line Current (A) | 0.55|0.62 |
| Power Rating (W) | 56|67.8 |
| Nominal Speed (r/min) | 2100|2000 |
| Maximum Airflow (CFM) | 630|680 |
| Maximum Pressure | 0.346inH2O|0.276inH2O |
| Noise Level (dB) | 66|62 |
| Bearings | Ball |
| Shape | Round |
| Size (mm) | 254 X 89 |
| Mounting | Flange Mount |
| Protection | Thermal |
| Minimum Operating Temperature (°C) | -10 |
| Maximum Operating Temperature (°C) | 60 |
| Product Weight (g) | 2000 |
| Product Diameter (mm) | 254 |
| Product Height (mm) | 89 |
