C&K Switches RTF 7.2mm Coded Rotary DIP Switches
C&K Switches ATP Anti-Vandal Sealed Pushbutton Switches are high-strength, lightweight switches that are IP67 rated, ensuring their suitability for operating in harsh conditions and their ability to withstand potential malicious damage. C&K ATP switches are also corrosion-resistant and offer an industry-standard ring version in 19mm and 22mm diameters. These UL-certified switches use a scratch-resistant actuator with housings made from robust stainless steel, making them particularly effective for use in remote and unsupervised locations where resilience to damage from vandalism is vital. ATP offers a range of actuator styles and a variety of illumination indicator colors. ATP19 offers actuation interfaces with a fixed-ring, spot, raised, raised-spot, raised-power, and dome configurations. ATP22 is avaialble with flat, moving-ring, and ring-plus-power-indicator actuators.
Description
FEATURES
- Compact, new-generation rotary DIP switches
- Thru-hole, crimped, J-hook, angled, and surface mount models
- New designs with different actuators
- IP67 ingress protection
- RoHS compatible and compliant
SPECIFICATIONS
- Contact rating
- 100mA, 5VDC (switching)
- 100mA, 50VDC (non-switching)
- 10,000 cycles mechanical and electrical life
- 100mΩ maximum initial contact resistance
- 100MΩ minimum insulation resistance
- -25°C to +85°C operating temperature range
- 200gf maximum operating force
APPLICATIONS
- 5G
- Industrial and control automation
- Computers and peripherals
- Banking ATMs
- Retail point of sale (POS)
- Telecommunications
- Consumer headsets
- Earth-leakage circuit breakers (ELCBs)
- Instrumentation
- Security devices
